ITEM |
D-LITE | D-LITE(0) | ERA | MAGNA | MAGNA(0) | SPORTZ |
Dimensions |
|
| Overall Length (mm) |
3,495 |
| Overall Width (mm) |
1,550 |
| Overall Height (mm) |
1,500 |
| Wheelbase (mm) |
2,380 |
| Front Track (mm) |
1,386 |
| Rear Track (mm) |
1,368 |
| Ground Clearance (mm) |
170 |
| Fuel Tank Capacity (I) |
32 |
| Boot Space (I) |
215 |
| |
|
Engine |
|
| Configuration |
3 Cyl, 9 Valves |
| Valvetrain Type |
SOHC |
| Displacement (cc) |
814 |
| Maximum Power (ps / rpm) |
56/5,500 |
| Maximum Torque (kgm / rpm) ARAI |
7.6/4,000 |
| Mileage (kmpl) |
21.1 |
| |
|
Transmission |
|
| Type |
5-Speed Manual |
| |
|
Suspension |
|
| Front |
McPherson Strut with Coil Spring & Anti-Roll Bar |
| Rear |
Torsion Beam Axle with Coil Spring |
| Shock Absorber |
Gas type |
| |
|
Brake |
|
| Front |
Disc |
| Rear |
Drum |
| |
|
Tyre |
|
| Size & Type (Tubeless) |
145/80 R12 ED-Lite, D-Lite(0), Era) |
155/70 R13 [Magna, Magna(0) Sportz] |
|
|
| |
|
|
| |
All the given features are subjected to change without
any prior notice |
|
| |
|
|
| |
|
|
| |
 |
|
| |
|
|
